Sanden SD7H15HD Air Compressor for Multi Fit Applications, 1 Wire Male Packard w/ Diode MEI/Air Source 5764

Technical Information:

• Make: Sauden
• Voltage: 12V
• Clutch Diameter: 132mm
• Number of Grooves: 2 Groove
• Belt Type: Two 1/2″ Belts
• Number Comp. Cylinders: 7
• Comp. Displacement (ci): 9.5 .
• Factory Oil Charge: 240cc Oil
• Fitting Port Position: Vertical
• Fitting Style: Male Insert O-Ring
• Head Type: JD
• Wire Type: 1 Wire Male Packard w/ Diode
• Replacement Clutch Assembly: 5064A
• Replacement Head Assembly: 5626
• Model: SD7H15HD
• Oil Type: PAG100
• Refrigerant Type: R134A
• Rotation: CW
• O-Rings: 0013 & 0015
• Shaft Type: Long Key Shaft
• Diode Protection: With Diode

Application Information: Multi Fit Applications
Product Condition: New
