Description
Technical Information
- Mounting: 5/16-18 UNC-2A Stud (2x)
- Supply Port 1: 1/2-14 NPT
- Maximum Operating Temperature: 200 °F (93 °C)
- Minimum Operating Temperature: -40 °F (-40 °C)
- Exhaust Port: Dust Shield
- Body Configuration: 1 SUP / 4 DEL (V)
- Control Secondary Service Port: 1/4-18 NPT
- Delivery Port 1: 1/2-14 NPT
- Delivery Port 2: 1/2-14 NPT
- Delivery Port 3: 1/2-14 NPT
- Delivery Port 4: 1/2-14 NPT
- Crack Pressure: 4.0 PSI
- TMC Washer: RV040
- Mounting Bracket Location: Loose in. Box
- Control Port Orientation CW from Front Face: 0°
- Balance Primary Service Port: 1/8-27 NPT (with Cover)
