Name: On - Off - None Toggle Switch, 4 Tin-Plated Blade 59024-14BX Cole Hersee
SKU: SK0105975-A
Availability: InStock

On – Off – None Toggle Switch, 4 Tin-Plated Blade 59024-14BX Cole Hersee

Description

Up: On, Center: Off. Terminals are arranged to match OEM wiring connectors. 59024-00 series available with or without brackets. Silver contacts. Black phenolic switch housing with metal cap. 15/32″ -32 thread mounting stem. Fits panels to .093″ (2.4mm) with spacer provided, or to .25″ (6.4mm) without spacer. Includes mounting hardware: black metal facenut. Keyway is in the down position. Black plastic 1″ (25.4mm) handle, matte finish. Four tin-plated blade terminals. 25A at 12V DC.

Technical Information

Current Rating (Continuous) in Amps: 25
Voltage Rating (Max): 12
Circuitry: DPST
Positions: On – Off – None
Input Terminals: 4 Tin-Plated Blade
Housing: Black Plastic with Metal Cap
Actuator: Paddle
Actuator Details: Black Plastic – 25.4mm
Mouting Method: 2 Nickel Plated Brass Hex Nuts
Panel Thickness: 0.093 (2.4mm) to .25 (6.4mm) thick
Contact Material: Silver
