Lippert Triple Axle Suspension Kit – 3″ Axle Tube, 35″ Axle Spacing, 20-3/8″ Leaf (1,000 lb), Long Equalizer, Hangers & Hardware – Fits Dexter, Alko, Rockwell, Quality Axles

Lippert Triple Axle Suspension Kit – 3″ Axle Tube, 35″ Axle Spacing, 20-3/8″ Leaf (1,000 lb), Long Equalizer, Hangers & Hardware

Upgrade or maintain your trailer’s suspension with this comprehensive Lippert Triple Axle Suspension Kit. Designed to fit Dexter, Alko, Rockwell, and Quality Axles, it features 1,000 lb leaf springs (20-3/8″ unloaded length), a long equalizer, plus heavy-duty hangers and hardware to keep your setup rolling smoothly and safely.

Bundle Contents:

• QTY (6): 21″ Leaf Spring – 1,000 lbs
  • Unloaded length: 20-3/8″
  • Loaded length: 21″
  • Arch height (unloaded): 2-7/8″
  • Arch height (loaded): 2-1/8″
  • Spring eye diameter: 9/16″
  • 1-3/4″ wide, 3 leaves per spring
• QTY (1): Triple Axle AP Kit with Long Equalizer and Standard Bolts
  • Includes shackle links, standard bolts, and hardware
  • Long equalizer design for smoother ride
  • Direct replacement for OE suspension components
• QTY (3): Lippert Axle Mounting Kit – 3″ Tube
  • U-bolt design sized for 3″ axle tubes
  • Installs quickly and securely
  • Replaces your worn or damaged mounting hardware
• QTY (2): Front Trailer Axle Hanger – 4-5/16″ x 2-3/16″, 2,200–8,000-lb. Axle Rating
  • Length: 4-5/16″
  • Width: 2-3/16″
  • Distance to hole (on-center): 3-9/16″
  • Hole size: 9/16″
• QTY (4): Center Trailer Axle Hanger – 4-1/2″ x 3-1/8″, 2,200–8,000-lb. Axle Rating
  • Length: 4-1/2″
  • Width: 3-1/8″
  • Distance to hole (on-center): 3-5/16″
  • Hole size: 7/8″
• QTY (2): Rear Trailer Axle Hanger – 6″ x 2-1/4″, 2,200–8,000-lb. Axle Rating
  • Length: 6″
  • Width: 2-1/4″
  • Distance to hole (on-center): 4″
  • Hole size: 5/16″

Always verify compatibility with your existing components. Refer to your trailer’s service manual for recommended maintenance intervals and proper installation procedures.

Specifications:
Kit Type	Complete Triple Axle Suspension Kit
Axle Rating	2,200–8,000 lbs
Leaf Spring Capacity	1,000 lbs Each
Number of Leaves per Spring	3
Leaf Spring Width	1-3/4″
Unloaded Eye-to-Eye Length	20-3/8″
Loaded Eye-to-Eye Length	21″
Arch Height Unloaded	2-7/8″
Arch Height Loaded	2-1/8″
Spring Eye Diameter	9/16″
Axle Tube Diameter	3″
Equalizer Type	Long Equalizer
Axle Configuration	Triple Axle
