Lippert Triple Axle Suspension Kit – 2.375″ Axle Tube, 33″ Spacing, 1,000 lb Leaf Springs (20-3/8″ Unloaded), Standard Equalizer, Hangers & Hardware – Fits Dexter, Alko, Rockwell

Lippert Triple Axle Suspension Kit – 2.375″ Axle Tube, 33″ Spacing, 1,000 lb Leaf Springs (20-3/8″ Unloaded), Standard Equalizer

Upgrade or replace your triple axle trailer’s suspension system with this comprehensive Lippert kit. Featuring six 1,000 lb leaf springs (each with 20-3/8″ unloaded length), front/center/rear hangers, hardware, and a triple axle AP kit with a standard equalizer, this bundle delivers reliable performance for trailers compatible with Dexter, Alko, Rockwell, and other quality axles. Designed for a 2.375″ axle tube and 33″ axle spacing, installation is straightforward, helping you get back on the road with confidence.

Bundle Contents:

• QTY (6): 1,000 lb Leaf Springs
  • 3 leaves total
  • 1-3/4″ spring width
  • 20-3/8″ unloaded eye-to-eye length
  • 21″ loaded length
  • Arch height unloaded: 2-7/8″; loaded: 2-1/8″
  • Spring eye diameter: 9/16″
• QTY (1): Triple Axle AP Kit with Standard Equalizer & Bolts
  • Includes shackle links, hardware, and standard equalizers
  • Standard equalizer design for smoother towing
  • Installs like original equipment
• QTY (3): Lippert Axle Mounting Kit – 2.375″ Tube
  • For 2.375″ diameter axle tubes
  • U-bolt design for secure mounting
  • Reference your original hardware for fit
• QTY (2): Front Trailer Axle Hanger – 4-5/16″ x 2-3/16″
  • Welded to chassis for axle mounting
  • Axle capacity: 2,200 – 8,000 lbs.
  • Length: 4-5/16″; width: 2-3/16″
  • Hole size: 9/16″
  • Distance to hole: 3-9/16″ on-center
• QTY (4): Center Trailer Axle Hanger – 4-1/2″ x 3-1/8″
  • Axle capacity: 2,200 – 8,000 lbs.
  • Length: 4-1/2″; width: 3-1/8″
  • Hole size: 7/8″
  • Distance to hole: 3-5/16″ on-center
• QTY (2): Rear Trailer Axle Hanger – 6″ x 2-1/4″
  • Axle capacity: 2,200 – 8,000 lbs.
  • Length: 6″; width: 2-1/4″
  • Hole size: 5/16″
  • Distance to hole: 4″ on-center

Always verify these components match your trailer’s original equipment. Regular inspection and proper installation help ensure safe towing for the long haul.

Specifications:
Kit Type	Complete Triple Axle Suspension Kit
Axle Rating	2,200 – 8,000 lbs.
Leaf Spring Capacity	1,000 lbs.
Number of Leaves per Spring	3
Leaf Spring Width	1-3/4″
Unloaded Eye-to-Eye Length	20-3/8″
Loaded Eye-to-Eye Length	21″
Arch Height Unloaded	2-7/8″
Arch Height Loaded	2-1/8″
Spring Eye Diameter	9/16″
Axle Tube Diameter	2.375″
Equalizer Type	Standard
Axle Configuration	Triple
