Econoride Air Spring Rolling Lobe 566.ER9265 Econoride

Original price was: $119.16.Current price is: $29.79.

SKU: SK0105412-A Category: Air Brake Spring Brake Tag: Automann

Description

Description

Econoride
Steel Base

Ref. #: 9265, 1R12-375, 64288, S20124, S20413

Product Specifications

Type: Rolling Lobe
Load (Lbs) @ 80 PSI: 5500
Load (Lbs) @ 100 PSI: 7000
Natural Freq. (CPM): 61
Design Height (in): 15
Bottom Plate Type: Steel
Top Plate Hole/Stud Qty: 1
Top Plate Dia. (A): 9.00
Bottom Plate Hole/Stud Qty: 4
Bottom Plate Dia. (C): 9.48
Bottom Plate C to C Dia. (D): 4055″
Bottom Part Number: BS08998
Bumper: Yes
Min. Height: 7.4
Max. Height: 24.9
Max. Dia.: 12.6

Cross References: 9235, 9265, W013589235, Wour website customer service, W013589265, Wour website customer service, 1DK23L, 1T15MM-9, 1T15MW-10, our website customer service-066, 9 10-19, 6387
