Description
- IncludesAB9622PBracket, Use withSDN109Nut
- Plastic Base
Production Specifications
- Type: Rolling Lobe
- Load (lbs) @ 80 PSI: 5100
- Load (lbs) @ 100 PSI: 6400
- Natural Freq. (CPM): 103
- Design Height (in): 7.00″
- Bottom Plate Type: Plastic
- Top Plate Hole/Stud Qty: 1
- Top Plate Dia. (A): 9.00
- Top Plate C to C Dia. (B): N/A
- Bottom Plate Hole/Stud Qty: 1
- Bottom Plate Dia. (C): 8.19
- Bottom Plate C to C Dia. (D): N/A
- Bottom Part #: BS11561
- Bumper: No
- Bracket: AB9622P
- Min. Height: 3.90
- Max. Dia.: 11.40
Cross References: 68358, 9 9-9 P 859, 9547, W013589547, Wour website customer service, W015449547, Wour website customer service, W015449549, Wour website customer service, 1R11268, 1R11-268, C811004, C81-1004
