16.13″ LH Trailer Axle Camshaft for 12.25″ Dana-Spicer Brakes E9263 Euclid

Technical Information

• Effective Length: 16.13″
• Bushing Journal Length: 2.22″
• Camshaft Spline Count: 10
• Brake Diameter: 12.25″
• Left or Right: LH
• Camshaft Spline Diameter: 1.50″
• OE Mfg.: Dana-Spicer
• Head Type: 05
• Brake Hardware Kit: E10757 (With 1.00 in. O.D. Anchor Pin, E10756 (With 1.25 in. O.D. Anchor Pin)
• Camshaft Repair Kit: E2469 (Nylon Bushing)
• E5307 Bronze Spider Bushing
• Paired Camshaft: E9264
• Axle: Trailer
• Brake Type: Dana-Spicer
• Notes: 0794L/R Head Fast-Rise. Euclid fabricated open roller end brake shoe numbers are: E-2393A, E-2394A, and E-5303A
• Mfg. Part: Dana-Spicer M12WKL10-163

Application Information

• Application Information 1: WARNING: These camshafts are for use with fabricated brakes shoes only! DO NOT use these new camshafts with cast brake shoe or fabricated closed roller-end brake shoes.
• Application Information 2: WARNING: E-586, 1-1/2 in. Diameters, Brake Shoe Rollers must be used with this new head design. E-586 rollers are now available in Brake Repair Kits E-9281, E-9282 and E-9283.
• Application Information 3: WARNING: These camshafts should not be used in conjunction with old Fast-Rise camshafts on the same axle. The rate of brake application is different between the two head designs.

Parts Interchange 12310160401, D&E9263, 04631622, H10450L, M12WKL10163, 17735
